*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Mounting Type | Through Hole |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| RoHS Status | RoHS Compliant |
| ECCN Code | EAR99 |
| Pbfree Code | yes |
| Trim/Adjustable Output | YES |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| Terminal Position | DUAL |
| Number of Terminations | 6 |
| Pin Count | 6 |
| Reach Compliance Code | unknown |
| Applications | ITE (Commercial) |
| Output Voltage | 12V |
| Input Voltage-Nom | 12V |
| Nominal Input Voltage | 12V |
| Type | Isolated Module |
| Technology | HYBRID |
| Published | 2005 |
| Terminal Form | PIN/PEG |
| Voltage – Isolation | 500V |
| Voltage – Input (Max) | 18V |
| Voltage – Input (Min) | 9V |
| Mount | PCB, Through Hole |
| Length | 50mm |
| Output Power | 15W |
| Width | 45mm |
| Depth | 8.5mm |
| Package / Case | 6-DIP Module |
| Current – Output 1 | 1.3A |
| Output Current | 1.3A |
| Efficiency | 83% |
| Height | 8.382mm |
| Feature | Remote On/Off, OCP, OVP |
| JESD-30 Code | R-XDMA-P6 |
| Weight | 56.699046g |
| Operating Temperature | -20°C~71°C With Derating |
| Input Current | 1.57A |
| Approval Agency | CE, TUV, cULus |
| Size / Dimension | 1.97Lx1.77W x 0.33 H 50.0mmx45.0mmx8.5mm |
| Series | ZUS (15W) |
