*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Part Status | Active |
| RoHS Status | ROHS3 Compliant |
| Packaging | Bulk |
| Mounting Type | Through Hole |
| Mount | Through Hole |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| ECCN Code | EAR99 |
| Pbfree Code | yes |
| Trim/Adjustable Output | YES |
| JESD-609 Code | e3 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Terminal Position | DUAL |
| Published | 2013 |
| Qualification Status | Not Qualified |
| Voltage – Input (Max) | 100V |
| Applications | ITE (Commercial) |
| Type | Isolated Module |
| Number of Terminations | 9 |
| Voltage – Isolation | 3kV |
| Output Voltage | 5.5V |
| Voltage – Output 1 | 5.5V |
| Technology | HYBRID |
| Terminal Form | PIN/PEG |
| Efficiency | 90% |
| Power (Watts) | 75W |
| Max Power Dissipation | 75W |
| JESD-30 Code | R-XDMA-P9 |
| Package / Case | Half Brick |
| Feature | OCP, SCP |
| Input Voltage-Nom | 72V |
| Terminal Finish | MATTE TIN OVER NICKEL |
| Voltage – Input (Min) | 55V |
| Operating Temperature | -25°C~100°C |
| Height | 26.416mm |
| Size / Dimension | 2.28Lx1.86W x 1.04 H 57.9mmx47.2mmx26.4mm |
| Series | VE-J00? (75W) |
| Max Output Current | 13.64A |
| Base Part Number | VE-J4W |
