*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Part Status | Active |
| Trim/Adjustable Output | NO |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| RoHS Status | RoHS Compliant |
| Lead Free | Lead Free |
| Terminal Position | DUAL |
| Published | 2013 |
| Qualification Status | Not Qualified |
| Terminal Pitch | 2.54mm |
| Terminal Form | GULL WING |
| Number of Terminations | 5 |
| Max Power Dissipation | 1W |
| Output Power | 1W |
| Total Power Output-Max | 1W |
| Applications | ITE (Commercial) |
| Voltage – Output 1 | 12V |
| Output Voltage | 12V |
| Input Voltage-Nom | 12V |
| Type | Isolated Module |
| Approval Agency | UL |
| Voltage – Isolation | 3kV |
| Factory Lead Time | 9 Weeks |
| Technology | HYBRID |
| Time@Peak Reflow Temperature-Max (s) | 60 |
| Packaging | Cut Tape (CT) |
| Isolation | Isolated |
| Max Output Current | 84mA |
| Peak Reflow Temperature (Cel) | 245 |
| Feature | SCP |
| Control Mode | VOLTAGE-MODE |
| Efficiency | 80% |
| Voltage – Input (Max) | 13.2V |
| Voltage – Input (Min) | 10.8V |
| Protections | CURRENT |
| Width | 8.3mm |
| Package / Case | 8-SMD Module, 5 Leads |
| Operating Temperature | -40°C~105°C With Derating |
| Height | 7.366mm |
| Weight | 1.59999g |
| Size / Dimension | 0.50Lx0.32W x 0.29 H 12.8mmx8.2mmx7.3mm |
| JESD-30 Code | R-PDMA-G5 |
| Series | PES1-M (1W) |
