*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Number of Functions | 1 |
| Number of Circuits | 1 |
| RoHS Status | RoHS Compliant |
| Pbfree Code | yes |
| JESD-609 Code | e3 |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| Supply Voltage | 5V |
| Qualification Status | Not Qualified |
| Peak Reflow Temperature (Cel) | 260 |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Published | 2006 |
| Terminal Finish | Tin (Sn) |
| Number of Terminations | 28 |
| Number of Pins | 28 |
| Pin Count | 28 |
| Terminal Position | QUAD |
| Terminal Form | J BEND |
| Height Seated (Max) | 4.57mm |
| Halogen Free | Halogen Free |
| Supply Voltage-Max (Vsup) | 5.25V |
| Supply Voltage-Min (Vsup) | 4.75V |
| Output | TTL |
| Frequency (Max) | 80MHz |
| Differential – Input:Output | Yes/No |
| Technology | ECL |
| Subcategory | Clock Drivers |
| Operating Temperature | 0°C~85°C |
| Package / Case | 28-LCC (J-Lead) |
| Low Level Output Current | 48mA |
| Type | Fanout Buffer (Distribution) |
| Family | 10H |
| Ratio – Input:Output | 1:8 |
| Logic Function | Translator |
| Same Edge Skew-Max (tskwd) | 0.5 ns |
| Propagation Delay | 5.1 ns |
| Turn On Delay Time | 5.9 ns |
| Max I(ol) | 0.048 A |
| High Level Output Current | -15mA |
| Power Supplies | 5-5.2V |
| Input | ECL, TTL |
| Voltage – Supply | 4.75V~5.25V -4.68V~-5.72V |
| Base Part Number | MC10H643 |
