*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Surface Mount |
| Number of Functions | 1 |
| Number of Circuits | 1 |
| Surface Mount | YES |
| JESD-609 Code | e3 |
| Part Status | Obsolete |
| Number of Terminations | 8 |
| Pin Count | 8 |
| Terminal Position | DUAL |
| Supply Voltage | 5V |
| Packaging | Tube |
| Operating Temperature | -40°C~85°C |
| Qualification Status | COMMERCIAL |
| Pbfree Code | no |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Reach Compliance Code | unknown |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Length | 3mm |
| Width | 3mm |
| Terminal Pitch | 0.65mm |
| Terminal Finish | MATTE TIN |
| Package / Case | 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) |
| Differential – Input:Output | Yes/Yes |
| Supply Voltage-Min (Vsup) | 4.2V |
| Technology | ECL |
| JESD-30 Code | S-PDSO-G8 |
| Ratio – Input:Output | 1:2 |
| Frequency (Max) | 1.5GHz |
| Type | Fanout Buffer (Distribution) |
| Supply Voltage-Max (Vsup) | 5.7V |
| Voltage – Supply | 4.2V~5.7V |
| Output | ECL, PECL |
| Input | ECL, PECL |
| Series | 10EL |
| Same Edge Skew-Max (tskwd) | 0.02 ns |
| Propagation Delay (tpd) | 0.34 ns |
| Additional Feature | NECL MODE: VCC=0 WITH VEE= -4.2V TO -5.7V |
